Eaton Carter 64349 is a 2½-inch underwing refueling nozzle qualified in accordance with SAE AS5877 (MIL-N-5877). It connects to 3-lug international standard aircraft adapters and offers various optional configurations.
Icon Frequently Asked Questions - Eaton Carter - 64349 Underwing Refueling Nozzle
What are the key features of the 64349 nozzle? toggle
  • Easy swiveling under all conditions: Swivel is independent of the quick disconnect coupling.
  • Self-adjusting pressure-loaded nose seal: Ensures leak-free operation under extreme conditions.
  • Positive mechanical interlock: Prevents fuel flow until securely connected to the aircraft adapter.
  • Modular construction: Supports optional inlet configurations, including dry break disconnects and strainers.
What are the operating specifications of the 64349 nozzle? toggle
  • Operating pressure range: Up to 200 psi (13.8 bar)
  • Rated flow: Up to 600 gallons per minute (2271 liters per minute)
  • Pressure drop: Under 12 psi (0.83 bar) at 600 gpm flow
  • Operating temperature range: Not specified.
